    Spartan 3000 Gallon Tanker

    Home / New Delivery / Spartan 3000 Gallon Tanker
    Type I – Classic on a Ford F-550 Chassis

    Description

    Overall Vehicle Dimensions:
    Length: 302″
    Width: 99″
    Height: 112″

    Exterior Modular Body Dimensions:
    Length: 170″
    Width: 97″
    Height: 91″

    Interior Modular Body Dimensions:
    Length: 165″
    Width: 90 3/4″
    Height: 72″

    Ford F550 Chassis Cab Four Wheel Drive
    Wheelbase 189″ – 108″ CA Dual Rear
    G.V.W. 18,000 lbs.
    Powertrain/Functional:
    Engine: 6.7L “Powerstroke” Turbo Diesel V8 300 hp.
    Single Stage Turbo Charger
    Instant Start Glow Plugs for quick engine starts
    Diesel Emissions Fluid 6 gallon tank
    Intelligent Oil Life Monitor
    Engine block heater
    Water Pump with 125 gallons per minute flow rate

    Transmission: Heavy Duty “TorqShift” Six Speed
    Select Shift Automatic with overdrive
    Electronic Shift on the Fly with automatic locking
    front hubs with manual override.
    Brakes – 4 wheel Anti-lock Braking System
    Traction Control – DRW Models
    Fuel Capacity: 40 gallon single tank (aft axle)
    Front Axle: 7,000 lb. Monobeam, Dana Super 60
    Rear Axle: 13,660 lb. Full Floating Dana S110 Suspension:
    Heavy Duty Front Coil Springs (7,000 lbs.)
    Rear Leaf Springs, main & auxiliary (13,660 lbs)
    Shock absorbers, front & rear 1.38″
    Stabilizer bar, front and rear
    Power Steering
    Steering Damper
    Rear axle 4.10 Limited Slip
    Auxiliary transmission oil cooler
    Dual OEM HD Alternators (total 355 amps)
    Dual 750 CCA Batteries
    Stationary elevated idle control (SEIC)

    Safety/Security:
    Driver/Passenger frontal and side air bag/curtain
    Passenger side air bag deactivation switch
    Belt-Minder – chime & flashing warning light on instrument panel if belts not buckled
    Safety Belts – color coordinated with height adjustment (front outboard seating positions only)
    SOS Post-Crash Alert System
    Securi-lock Anti Theft Ignition
    Tires:
    Front & Rear LT225/70R 19.5G All Season (6)
    Spare Tire: LT225/70R 19.5G (All Season)
    Wheels; 10 hole Disc, 19.5″ x 6″ POLISHED ALUMINUM
    Exterior Trim:
    Dual Electric Horns
    Chrome Front Bumper & Grille Surround
    Mirrors: Black Manually Telescoping Trailer tow
    w/Power-Heated Glass, integrated clearance lights and two way fold away
    Front Tow Hooks
    Lights – roof/marker clearance lights
    Under Hood Service Light
    Dual Beam Jewel Effect Headlights
    XLT Interior Cab Trim:
    Air Conditioning
    Cloth Headliner, Map Pockets
    AM/FM Radio w/CD/Mp3 Player/Clock
    Interval Windshield Wipers
    Tilt Steering Wheel/Speed Control – steering wheel mounted
    Power Windows/Door Locks
    Color-keyed Carpet / Floor Mats
    Headlights on audible alarm
    Dual overhead Map Light
    Daytime Running Lights
    Front seats, high series cloth – 40/20/40

    Delivery Date:
    12/20/2013
    Department Name:
    Littleton FD
    Location:
    Littleton, MA
    Categories:
    • Ambulances
