    WALK IN RESCUE ON A SPARTAN LTD CHASSIS

    Type I – Classic on a F-350 Chassis

    Description

    Overall Vehicle Dimensions:
    Length: 278″
    Width: 99″
    Height: 108 1/4″

    Exterior Modular Body Dimensions:
    Length: 147″
    Width: 97″
    Height: 91″

    Interior Modular Body Dimensions:
    Length: 140″
    Width: 90 3/4″
    Height: 72″

    Chassis:
    Ford F350 Chassis Cab Two Wheel Drive
    Wheelbase 165″ – 84″ CA Dual Rear
    G.V.W. 13,300 lbs.
    Powertrain/Functional:
    Engine: 6.7L “Powerstroke” Turbo Diesel V8 300
    hp @2800 RPM, 660 lbs torque @1600 RPM
    Single Stage Turbo Charger
    Instant Start Glow Plugs for quick engine starts
    Diesel Emissions Fluid 6 gallon tank – mounted
    behind frame rail on drivers side
    Intelligent Oil Life Monitor
    Engine block heater
    Water Pump with 125 gallons per minute flow rate

    Transmission: Heavy Duty “TorqShift” Six Speed
    Select Shift Automatic with overdrive
    Brakes – 4 wheel Anti-lock Braking System
    Traction Control – DRW Models
    Fuel Capacity: 40 gallon single tank (aft axle)
    Front Axle: 5,250 Twin I Beam IFS, Ford
    Rear Axle: 9,750 Full Floating Dana 80
    Suspension:
    Heavy Duty Front Coil Springs (5,250bs.)
    Rear Leaf Springs, main & auxiliary (9,750 lbs)
    Shock absorbers, front & rear 1.38″
    Stabilizer bar, front and rear
    Power Steering
    Steering Damper

    Instrumentation: multifunction switch message center –
    Gauges: Oil Pressure, Coolant Temperature, Trans Temp,
    w/Indicator Lights, Tachometer, Trip Odometer, Turbo boost,
    water in fuel warning light, low/contaminated diesel exhaust
    fluid warning lights, glow plug preheat indicator
    Ambulance Prep Package – 47A
    Rear axle 4.10 Limited Slip
    Auxiliary transmission oil cooler
    Dual OEM HD Alternators (total 355 amps)
    Dual 750 CCA Batteries
    Stationary elevated idle control (SEIC)

    Safety/Security:
    Driver/Passenger frontal and side air bag/curtain
    Passenger side air bag deactivation switch
    Belt-Minder – chime & flashing warning light on instrument panel if belts not buckled
    Safety Belts – color coordinated with height adjustment (front outboard seating positions only)
    SOS Post-Crash Alert System
    Securi-lock Anti Theft Ignition
    Tires:
    Front & Rear LT245/75R 17E All Season (6)
    Spare Tire: LT245/75R 17E (All Season)
    Wheels; 8 hole Disc, 17″ x 6.5″ Steel
    Exterior Trim:
    Dual Electric Horns
    Chrome Front Bumper & Grille Surround
    Mirrors: Black Manually Telescoping Trailer tow
    w/Power-Heated Glass, integrated clearance lights and two way fold away
    Front Tow Hooks
    Lights – roof/marker clearance lights
    Under Hood Service Light
    Dual Beam Jewel Effect Headlights
    XLT Interior Cab Trim:
    Air Conditioning
    Cloth Headliner, Map Pockets
    AM/FM Radio w/CD/Mp3 Player/Clock
    Interval Windshield Wipers
    Tilt Steering Wheel/Speed Control – steering wheel mounted
    Power Windows/Door Locks
    Color-keyed Carpet / Floor Mats
    Headlights on audible alarm
    Dual overhead Map Light
    Daytime Running Lights
    Front seats, high series cloth – 40/20/40

    Color Scheme:
    Exterior Color: Oxford White #Z1
    Interior Color: Steel Gray

    Delivery Date:
    2/21/2013
    Department Name:
    South Kingstown EMS
    Location:
    South Kingstown, RI
    Categories:
    • Ambulances
    Ask About this Truck
