    Spartan 3000 Gallon Tanker

    Home / New Delivery / Spartan 3000 Gallon Tanker
    Type 1 Classic on a Ford Chassis

    Description

     Overall Vehicle Dimensions:

            Length: 302″

            Width:  99″

            Height: 112″

        Exterior Modular Body Dimensions:

            Length: 170″

            Width: 97″

            Height: 91″

        Interior Modular Body Dimensions:

            Length: 165″

            Width: 90 3/4″

            Height: 75″

    Ford F450 Chassis Cab Four Wheel Drive

    Wheelbase 189″ – 108″ CA Dual Rear

    G.V.W. 16,500 lbs.

    Powertrain/Functional:

    Engine: 6.7L “Powerstroke” Turbo Diesel V8 300

    hp @2800 RPM, 660 lbs torque @1600 RPM

    Single Stage Turbo Charger

    Instant Start Glow Plugs for quick engine starts

    Diesel Emissions Fluid 6 gallon tank – mounted

    behind frame rail on drivers side

    Intelligent Oil Life Monitor

    Engine block heater

    Water Pump with 125 gallons per minute flow rate



    Transmission: Heavy Duty “TorqShift” Six Speed

      Select Shift  Automatic with overdrive

    Electronic Shift on the Fly with automatic locking

      front hubs with manual override.

    Brakes – 4 wheel Anti-lock Braking System

    Traction Control – DRW Models

    Fuel Capacity: 40 gallon single tank (aft axle)

    Front Axle: 7,000 lb. Monobeam, Dana Super 60

    Rear Axle: 12,000 lb. Full Floating Dana S110

    Suspension:

    Heavy Duty Front Coil Springs (7,000 lbs.)

    Rear Leaf Springs, main & auxiliary (12,000 lbs)

    Shock absorbers, front & rear 1.38″

    Stabilizer bar, front and rear

    Power Steering

    Steering Damper



    Instrumentation: multifunction switch message center –

    Gauges: Oil Pressure, Coolant Temperature, Trans Temp,

    w/Indicator Lights, Tachometer, Trip Odometer, Turbo boost,

    water in fuel warning light, low/contaminated diesel exhaust

    fluid warning lights, glow plug preheat indicator

    Ambulance Prep Package – 47A

    Rear axle 4.10 Limited Slip #X4N

    Auxiliary transmission oil cooler

    Dual OEM HD Alternators (total 355 amps)

    Dual 750 CCA Batteries

    Stationary elevated idle control (SEIC)

    Operated Commanded Regeneration (OCR) #98R



    Safety/Security:

    Driver/Passenger frontal and side air bag/curtain

    Passenger side air bag deactivation switch

    Belt-Minder – chime & flashing warning light on instrument panel if belts not buckled

    Safety Belts – color coordinated with height adjustment (front outboard seating positions only)

    SOS Post-Crash Alert System

    Securi-lock Anti Theft Ignition

    Tires:

    Front & Rear LT225/70R 19.5G All Season (6) #TFB

    Spare Tire: LT225/70R 19.5G (All Season)

    Wheels; 10 hole Disc, 19.5″ x 6″ Steel

    Exterior Trim:

    Dual Electric Horns

    Chrome Front Bumper & Grille Surround

    Mirrors:  Black Manually Telescoping Trailer tow

    w/Power-Heated Glass, integrated clearance lights and two way fold away

    Front Tow Hooks

    Lights – roof/marker clearance lights

    Under Hood Service Light

    Dual Beam Jewel Effect Headlights

    XLT Interior Cab Trim: #653A

    Air Conditioning

    Cloth Headliner, Map Pockets

    AM/FM Radio w/CD/Mp3 Player/Clock

    Interval Windshield Wipers

    Tilt Steering Wheel/Speed Control – steering wheel mounted

    Power Windows/Door Locks

    Color-keyed Carpet / Floor Mats

    Headlights on audible alarm

    Dual overhead Map Light

    Daytime Running Lights

    Front seats, high series cloth – 40/20/40 #3S



    Delivery Date:
    8/5/2016
    Department Name:
    North Kingstown FD
    Location:
    North Kingstown, RI
    Categories:
    • Ambulances
